These resources were created so that members of 771 would always have access to detailed technical lessons, teaching them everything they need to know to get started in mechanical and design. However, these are resources that could be used by any team. Lessons can be presented in a meeting or learned from on one’s own. The full website for these resources, “FRC tutorials“, was made to contain all of this knowledge in one place, including lessons made by SWAT members, in addition to all of the other incredible resources linked.

Mechanical Lessons

And for more technical lessons/resources, find them here.

Screen Shot 2018-08-19 at 9.51.24 PM.png
> Mechanical Lesson #1: Intro To Mechanical
Covering FRC suppliers, materials used to build robots, and common tools to manufacture parts.
Screen Shot 2018-08-19 at 9.59.32 PM.png
> Mechanical Lesson #2: Motor Selection
Covering common FRC motors, motor characteristics, and gear calculations.
Screen Shot 2018-08-19 at 10.05.00 PM.pn
> Mechanical Lesson #3: All About Motion
Covering the basics of motion, gearboxes, methods of power transmission, and about air cylinders.
